Hebei Huayang Steel Pipe Co., Ltd is one of the leading manufacturers and suppliers of astm a500 grade a hfw structural steel pipe for light-duty building frames in China. Please feel free to buy cheap astm a500 grade a hfw structural steel pipe for light-duty building frames from our factory. All customized products are with high quality and low price.
Product Overview
Huayang ASTM A500 Grade A HFW structural steel pipe is designed for building frames and general structural applications requiring consistent dimensions and reliable welded performance.
| Parameter | Specification |
|---|---|
| Material Grade | ASTM A500 Grade A |
| Standard | ASTM A500/A500M |
| Manufacturing Process | HFW |
| Welding Method | High-Frequency Welding |
| Product Type | Welded Structural Steel Pipe |
| Main Application | Light-Duty Building Frames |
ASTM A500/A500M covers cold-formed welded and seamless carbon steel structural tubing in round and shaped sections for welded, riveted or bolted construction.
ASTM A500 Grade A Material Performance
ASTM A500 Grade A is a carbon steel structural grade with a minimum tensile strength of 310 MPa and minimum yield strength of 230 MPa for round sections. It provides suitable strength and formability for general building frames, supports and fabricated structural components. The HFW process creates a continuous longitudinal seam by heating the formed steel strip with high-frequency electrical current and applying pressure to join the edges. Huayang can provide dimensional inspection, weld quality checks and mechanical testing according to the applicable specification and project requirements. Structural design should confirm the required section dimensions, load capacity and applicable building code.
Our Certificate
Bundling and loading onto vehicles
Pipe Detaild Packages
| Specification | Pcs per Bundle | Bundling Layer Pattern | CBM per Bundle | |
| OD (mm) | Wall Thickness (mm) | |||
| 48.3 | 3.68 | 91 | 6,7,8,9,10,11,10,9,8,7,6 | 1.69 |
| 5.08 | 61 | 5,6,7,8,9,8,7,6,5 | 1.13 | |
| 60.3 | 3.91 | 61 | 5,6,7,8,9,8,7,6,5 | 1.77 |
| 5.54 | 37 | 4,5,6,7,6,5,4 | 1.07 | |
| 73 | 5.16 | 37 | 4,5,6,7,6,5,4 | 1.57 |
| 7.01 | 24 | 4,5,6,5,4 | 0.96 | |
| 88.9 | 5.49 | 24 | 4,5,6,5,4 | 1.42 |
| 7.62 | 19 | 3,4,5,4,3 | 1.19 | |
| 114.3 | 6.02 | 19 | 3,4,5,4,3 | 1.96 |
| 8.56 | 10 | 3,4,3 | 0.94 | |
| 141.3 | 6.55 | 10 | 3,4,3 | 1.44 |
| 9.53 | 7 | 2,3,2 | 1.08 | |
| 168.3 | 7.11 | 10 | 3,4,3 | 2.04 |
| 10.97 | 7 | 2,3,2 | 1.53 | |
| 219.1 | 8.18 | 7 | 2,3,2 | 2.59 |
| 12.7 | 5 | 2,3 | 1.73 | |
| 273 | 9.27 | 5 | 2,3 | 2.68 |
| 15.09 | 3 | 1,2 | 1.79 | |
| 323.8 | 10.31 | 3 | 1,2 | 2.52 |
| 17.48 | 2 | 1,1 | 1.26 | |
Pipe Protection
Pipe-end protection is advisable in case the pipe-ends are bevelled at the pipe manufacturer. In the case of overseas transport, there is an especially increased risk of damaged pipe-ends. This is caused by extra handling procedures in ports and shifting of the pipes onboard vessels.
In addition to end caps or protective rings, external wrapping with protective cloth can be applied along the pipe body. This wrapping helps to safeguard the coating surface from scratches, moisture, and contamination during long-distance transportation or prolonged outdoor storage. Especially for coated or painted pipes, the additional protective cloth layer significantly reduces the risk of mechanical damage, UV exposure, and corrosion initiation, ensuring the pipes arrive at the destination in optimal condition.
Pipe Painting Services
In addition to pipe-end protection and external wrapping, Huayang provides customized steel pipe painting services to meet different project specifications and environmental requirements. Available options include water-based eco-friendly quick-drying paint, epoxy paint, quick-drying black paint, bituminous paint, and high-temperature-resistant paint. Paint type and application can be selected according to customer requirements, providing suitable surface protection for transportation, storage, and service conditions.
Steel Pipe Deep Processing
Beyond standard steel pipe manufacturing, Huayang provides customized deep processing services to meet different project and installation requirements. Our capabilities include flange welding, loose flange assembly, steel pipe piles, extra-long pipe joining, end beveling, and other fabrication services. Processing can be carried out according to customer drawings, technical specifications, and project requirements, helping customers reduce on-site fabrication work and improve installation efficiency.
|
Processing Items |
Diameter Range |
Wall Thickness |
Length |
|
Beveling Squaring |
60~1422 |
4~20mm |
1~20m |
|
Pipe Straightening |
219~820 |
4~25mm |
6.5~20m |
|
Hydrostatic Testing |
76~1422 |
4~50mm |
8~12.5m |
|
Pipe Bundling |
60~457 |
Bundle as per the customer's requirements |
|
|
Extra-long butt welding of steel pipe |
219~6000 |
No restrictions |
≤60m |
|
Pipe Prefabrication (Flange connection) |
Steel pipe welding & prefabrication can be customised to drawings |
≤60m |
|
|
Steel Support Welding Processing |
≤60m |
||
|
Steel Pipe Pile Welding (Clutch) |
≤32m |
||
|
Pipe Truss Assembly Welding |
≤60m |
||
|
Steel Pipe Pile Stud Welding |
≤60m |
||
|
Wrap the steel pipe |
2.5~12m |
||
|
Coil Uncoiling, Width and Thickness Range |
|||
|
Material |
Uncoiling |
Width, Thickness |
Uncoiling Length |
|
Q235B |
1~2.1m |
8~19mm |
6~13m |
|
Q355B |
1~2.1m |
8~16mm |
6~13m |
