Hebei Huayang Steel Pipe Co., Ltd is one of the leading manufacturers and suppliers of api 5l gr.b dn200 erw steel pipe line pipe in China. Please feel free to buy cheap api 5l gr.b dn200 erw steel pipe line pipe from our factory. All customized products are with high quality and low price.
Product Overview
Huayang DN200 ERW line pipe is manufactured for pipeline systems requiring consistent dimensions, reliable weld integrity, and stable mechanical performance.
| Parameter | Specification |
|---|---|
| Outside Diameter | 219.1 mm |
| Nominal Diameter | DN200 |
| Material Grade | API 5L Grade B PSL1 |
| Manufacturing Process | High Frequency ERW |
| Wall Thickness | 5.0–18.0 mm |
| Main Application | Line Pipe |
The DN200 diameter provides a practical solution for medium-capacity transmission and distribution pipelines.
Material Performance and Application
API 5L Grade B PSL1 is a widely used carbon steel line pipe grade, offering a minimum yield strength of 245 MPa and a minimum tensile strength of 415 MPa. Its relatively low carbon content and balanced chemical composition provide good weldability and reliable ductility, making it suitable for conventional pipeline transportation service. Huayang manufactures DN200 ERW pipe through controlled forming and high-frequency welding, with attention to weld quality, roundness, straightness, and dimensional tolerance. The pipe can be supplied for oil, gas, water, and industrial fluid transmission, with hydrostatic testing, weld inspection, mechanical testing, and chemical analysis performed according to the applicable specification. External FBE, 2PE, or 3PE coatings can also be applied when enhanced corrosion protection is required.
Our Certificate
Bundling and loading onto vehicles
Pipe Detaild Packages
| Specification | Pcs per Bundle | Bundling Layer Pattern | CBM per Bundle | |
| OD (mm) | Wall Thickness (mm) | |||
| 48.3 | 3.68 | 91 | 6,7,8,9,10,11,10,9,8,7,6 | 1.69 |
| 5.08 | 61 | 5,6,7,8,9,8,7,6,5 | 1.13 | |
| 60.3 | 3.91 | 61 | 5,6,7,8,9,8,7,6,5 | 1.77 |
| 5.54 | 37 | 4,5,6,7,6,5,4 | 1.07 | |
| 73 | 5.16 | 37 | 4,5,6,7,6,5,4 | 1.57 |
| 7.01 | 24 | 4,5,6,5,4 | 0.96 | |
| 88.9 | 5.49 | 24 | 4,5,6,5,4 | 1.42 |
| 7.62 | 19 | 3,4,5,4,3 | 1.19 | |
| 114.3 | 6.02 | 19 | 3,4,5,4,3 | 1.96 |
| 8.56 | 10 | 3,4,3 | 0.94 | |
| 141.3 | 6.55 | 10 | 3,4,3 | 1.44 |
| 9.53 | 7 | 2,3,2 | 1.08 | |
| 168.3 | 7.11 | 10 | 3,4,3 | 2.04 |
| 10.97 | 7 | 2,3,2 | 1.53 | |
| 219.1 | 8.18 | 7 | 2,3,2 | 2.59 |
| 12.7 | 5 | 2,3 | 1.73 | |
| 273 | 9.27 | 5 | 2,3 | 2.68 |
| 15.09 | 3 | 1,2 | 1.79 | |
| 323.8 | 10.31 | 3 | 1,2 | 2.52 |
| 17.48 | 2 | 1,1 | 1.26 | |
Pipe Protection
Pipe-end protection is advisable in case the pipe-ends are bevelled at the pipe manufacturer. In the case of overseas transport, there is an especially increased risk of damaged pipe-ends. This is caused by extra handling procedures in ports and shifting of the pipes onboard vessels.
In addition to end caps or protective rings, external wrapping with protective cloth can be applied along the pipe body. This wrapping helps to safeguard the coating surface from scratches, moisture, and contamination during long-distance transportation or prolonged outdoor storage. Especially for coated or painted pipes, the additional protective cloth layer significantly reduces the risk of mechanical damage, UV exposure, and corrosion initiation, ensuring the pipes arrive at the destination in optimal condition.
